S550Q siab zog qis alloy phaj



S550Q siab zog qis alloy phaj



S550Q siab lub zog Tsawg Alloy Steel Phaj yog qhov quenched thiab tempered lub zog loj steel phaj thiab muaj cov kws kho tshuab tshwj xeeb thiab ua kom ruaj khov.



S550Q tsawg alloy qauv txheej txheem muaj qhov muaj peev xwm loj tshaj plaws. "Q" txhais tau hais tias nws muaj kev cuam tshuam zoo nyob rau ntawm -20 degree, thiab tuaj yeem ntseeg tau siv hauv cov chaw txias, sab nraum zoov tshuab thiab lwm thaj chaw.



S550Q Lub Zog Siab Steel phaj tau siv dav hauv ntau cov teb, cov khoom siv tshuab hluav taws xob, chaw nres nkoj, siab tsis kam thiab cov txheej txheem zoo.



Gnee yog tus xa khoom ntawm aluminium steel daim hlau nrog 17 xyoo ntawm kev ua haujlwm. Cov khoom peb muab tau tuaj yeem kho tau qhov loj me thiab ntau yam kev pabcuam raws li koj cov kev xav tau kawg. Ib qho ntxiv, peb kuj tseem tuaj yeem muab S355j2 tsawg Alloy Steel, S690QL1 High paib lub zog steel thiab A70TO High-alloy High-zog Txheej Txheem Steel Hlau Phaj, thiab lwm yam.





Qhov tuab	2.75mm-100mm, raws li koj qhov kev thov
Qhov dav	600-2500mm, lossis raws li koj qhov kev thov
Lub hom phiaj	ASME, ASTM, DIN, JIS, GB, En, ETC.
Qib hlau	ASTM: A573 Qib 70, A709 Qib 50, A544 qib B, thiab lwm yam. ASME: SAURE573 Qib 70, SA709 Qib 50, SA544 qib B, thiab lwm yam. En: S355jr, S355JR, S355J0, S355K2, S355K, S355N, S355J2, S420N, S460N, S460Q, S460QL, S500Q, S500QL, S550Q, S500QL, S690Q, S690QL, S690QL1, S890Q, S80QL, S890QL1, S960Q, S960ql, thiab lwm yam. DIN: ST52-3, thiab lwm yam. JIS: SS490, SS540, SM490, thiab lwm yam. GB: Q355B, Q355D, Q390B, Q390D, Q420B, Q460D,Q460E,Q500D,Q500E,Q550D,Q550E, Q620D, Q620T, Q690D, Q690E, Q690E, Q890D, Q890E, Q960D, Q960E, thiab lwm yam.
Kev txawj	Kub Rolled
Nto Kho	Liab qab, dub, oiled, txhaj tshuaj tawg, tshuaj tsuag pleev xim, coated, galvanized, lossis raws li koj qhov kev thov
Daim ntawv thov	Siv rau cov cuab yeej siv siv, tshuab tsim khoom, thawv tsim, nkoj nkoj, txuas hniav, txuas ntxiv), thiab lwm yam.
Hais lus	Kev tuav pov hwm ib mus rau cov lus cog lus; MTC yuav muab tso rau nrog cov ntaub ntawv xa khoom; Peb lees txais cov ntawv pov thawj thib peb.





EU En	Lub teb chaws Yelemees Din, WNR	Fabkis Ib tug kaum	Laus Laus En
S550Q	STE550v	E550tr	Nqi zog hloov





Nominal tuab =< 50(mm) Lub TSHUABMax=0.65 Nominal tuab ntawm 50 txog 100 (hli)Lub TSHUABMax=0.77 Nyob ntawm cov tuab ntawm cov khoom lag luam thiab cov kev tsim khoom, cov chaw tsim khoom yuav ntxiv rau cov hlau ib lossis ob peb txoj kev sib dhos kom muaj txiaj ntsig tau txais cov khoom tshwj xeeb Nb, ti, v, zr: Yuav tsum muaj tsawg kawg yog 0.015% ntawm cov qoob loo-ua kom tsim hluav taws xob tam sim no.AlKuj tseem yog ib qho ntawm cov ntsiab lus no. Qhov tsawg kawg nkaus cov ntsiab lus ntawm 0.015% siv rau soluble aluminium, tus nqi no tau suav tias yog muaj yog tias cov ntsiab lus txhuas txhuas tsawg kawg yog 0.018%; Thaum muaj kev sib cav ntawm cov ntsiab lus soluble aluminium yuav tsum txiav txim siab

C

Si

Mn

Ni

P

S

Cr

Mo

V

N

Nb

Ti

CU

Tsaus yr

B

Lub TSHUAB

Max 0.2

Max 0.8

Max 1.7

Max 2

Max 0.025

Max 0.015

Max 1.5

Max 0.7

Max 0.12

Max 0.015

Max 0.06

Max 0.05

Max 0.5

Max 0.15

Max 0.005

Max 0.83







Nominal tuab (hli):	3 - 100	100 - 150
Rm- Tensile Lub Zog (Mpa)	640-820	590-770



Nominal tuab (hli):	3 - 50	50 - 100	100 - 150
Kub- Yam tsawg kawg nkaus tuaj lub zog (Mpa)	550	530	490



Kv- Tej yam cuam tshuam (J) LATURDD.,	0 Qib 40	-20 degree 30



A- Min. elongation lo=5}, 65 √ Yog li (%)	16















Peb txhawb nqa ntau yam tshwj xeeb, muaj ntau hom huab cua tiv thaiv steel phaj customization, yog tias koj muaj S550Q siab zog qis alloy phaj lossis lwm yam corten steel phaj khoom corten steel phaj khoom customization xav tau, thov hu rau peb!



Cim npe nrov: S550Q siab lub zog qis alloy phaj, Tuam Tshoj S550Q siab zog qis alloy phaj manufacturers, Hoobkas
